Filtration

Pressure Filters

STAUFF pressure filters are designed for the most demanding applications. They come in a variety of sizes, configurations and with numerous porting options.

  • pressures to 420 bar (6000 PSI)
  • flows to 1320 l/min (350 US GPM)
  • BSP, NPT, SAE “O”-ring or SAE Code 61 & 62 flange ports
  • head spheroidal graphite cast iron, bowl cold drawn steel
  • wide range of valve options
  • various element types and media available
  • standard bowls or top-loading bowls available
  • visual, electrical and visual-electrical indicators

Return Filters

Return filters are designed as tank top filters.Their practical design allows easy element replacement and quick installation.

A wide range of media is available for the RF-RTF element series.

  • pressure up to 16 bar (232 PSI)
  • flows up to 500 l/min (130 US GPM)
  • BSP, NPT, SAE “O”-ring and SAE Code 61 flange ports
  • head aluminum alloy, bowl glass fiber reinforced PA
  • visual and electrical indicators
  • STAUFF manufacturers a complete range of mobile filtration systems.

Compact in design and easy to operate on the one hand, but also made for permanent use with high flow rates on the other.

Spin On Filters

STAUFF manufacturers a wide range of high and low pressure spin-on fil- ters. A variety of filter head, element and indicator options are available.

Both North American as well as European spin-on elements are available from stock.

  • pressure to 14 bar (200 PSI)
  • flows to 460 l/min (120 US GPM)
  • BSP, NPT, SAE “O”-ring or SAE Code 61 flange ports
  • heads die-cast aluminum • visual and electrical indicators
  • a wide range of media types and seal options
  • European and North American elements in stock
DSC06538

McCullochs Hydraulic Engineers

Based in Bendigo, Central Victoria, we provide Hydraulic and Pneumatic engineering services to a broad cross-section of businesses throughout regional Victoria and Australia.

DSC06478

McCullochs Drilling & Boring

We are a drill rig manufacturer and distributor located in Victoria, Australia and have been operating for over 10 years. We work closely with Hanjin D&B in South Korea and Massenza Drilling Rigs in Italy as their exclusive distributer for the South Pacific Region and also Manufacture our own wholly Australian made and designed McCulloch DR950

DSC07727

kv eQUIPMENT

KV Equipment are Bendigo's premier farm equipment stockists, with a wide variety of consumables and equipment that keep your operations running smoothly. If you can't find a machine or part then let us know and we can chase it down for you.
